The R101/R72 Trapezoidal Roof Sheet Roll Forming Machine from Zhongtuo has become a leading solution in the Latin American metal roofing industry, especially in Mexico and Ecuador. Designed to produce high-quality trapezoidal roofing sheets in both R101 and R72 profiles, this machine is valued for its efficiency, adaptability, and low maintenance.
Dual Profile Production with Easy Switching
One of the key advantages of this machine is its ability to produce two different roofing profiles—R101 and R72—using a single production line. By supporting two coil input widths—914mm and 1220mm—the machine allows users to effortlessly switch between the two profiles. The transition between profiles is quick and straightforward, controlled through a user-friendly PLC system, eliminating the need for mechanical reconfiguration.
This feature makes the machine ideal for manufacturers who need flexibility to meet diverse customer demands or who are serving multiple regional standards.
High-Speed Operation and Reliable Output
The R101/R72 trapezoidal roofing machine operates at a working speed of 15–20 meters per minute, making it well-suited for medium to high-volume production. It is capable of processing pre-painted galvanized coils (PPGI) or galvanized steel (GI) with a thickness range from 0.3mm to 0.6mm. These materials are commonly used for durable roofing in both residential and commercial construction.
The production line includes a 5-ton manual decoiler, 16 forming stations, and a hydraulic cutting system that produces either 6-wave or 8-wave panels, depending on the profile required. The cutting head is engineered for precision, ensuring clean edges and accurate dimensions on every sheet.
All-in-One Turnkey Configuration
Zhongtuo’s R101/R72 Trapezoidal Roof Sheet Roll Forming Machine comes as a complete production solution. The line consists of:
Manual Decoiler: Capable of handling coils up to 5 tons.
Roll Forming Section: Equipped with high-precision chrome-coated rollers to shape the material without damaging the surface.
Hydraulic Cutting Unit: Two-pillar shear system for accurate cutting.
PLC Control Panel: Touchscreen interface for real-time adjustment and profile switching.
Run-Out Table: Supports finished panels for easy handling and stacking.
This integrated system reduces installation time and simplifies production management, making it ideal for both new and experienced manufacturers.
Widely Adopted in Latin America
In countries like Mexico, Ecuador, and Colombia, the R101/R72 machine is gaining strong market traction. Its popularity stems from its high output capacity, long-term reliability, and ability to meet varying local standards. Roofing contractors and panel suppliers favor it not only for its performance but also for its adaptability to different working environments.
Space-Saving Double-Layer Option
For clients with limited floor space or strict shipping constraints, Zhongtuo offers a double-layer roll forming version of the R101/R72 machine. This design allows two profiles to be formed using the same machine frame, but one layer at a time. It’s an excellent choice for businesses that need flexibility without sacrificing valuable workshop area.
The double-layer machine is also ideal for companies that operate in medium-volume production environments, offering efficiency without the cost of a full second machine.
Full Support and Customization Available
Zhongtuo provides comprehensive technical support, including installation guidance, operational training, and ongoing maintenance services. The machine can be customized to meet unique production requirements—such as profile depth, logo embossing, auto stacking, and more.
For clients who wish to see the machine in action or receive detailed layout drawings, our sales and technical teams are ready to assist. We have already delivered multiple units to roofing factories in Mexico and Ecuador with strong post-installation feedback.
Whether you’re expanding your production capacity or entering the metal roofing market, the R101/R72 Trapezoidal Roof Sheet Roll Forming Machine offers the flexibility, speed, and quality you need. Its dual-profile function, customizable design, and proven reliability make it a valuable investment for roofing sheet manufacturers across Latin America.
Contact Zhongtuo today to learn more about how this machine can improve your production line and help you meet the demands of a growing roofing industry.
